Produkt - ECClos-S

ECClos®-S

Product Description

The sheet metal slider is characterized by its robust sandwich construction with all-round sheet metal cover. It is suitable for interrupted and continuous conveyor systems such as belt, roller and chain conveyors. Segmented slide elements allow smooth transport to the installation site. Variable fixed fields enable the simple implementation of customized solutions.

ECClos-S

construction type

fire protection closure during ground bound conveyors

closing direction

from left to right • from right to left • from top to bottom

fire resistant

EI₁ 120 | (2 hours integrity and 2 hours minutes insulation) in accordance with European test standard according to EN 1366-7

closing cycle

C5 number of closing cycles 200.000

reopening

Motorised (standard) • manuell

conveying system

skid conveyor • downhill runway • interrupted conveyor systems • Continuous belt conveyor • Continuous travelling carriages • Continuous chain conveyor • continuous roller conveyor • continuous conveyor system

Downloads

System drawing - horizontal System drawing - Vertical
Constructive structure - System drawing - horizontal

a 187 b 590 c 410 f ≥ 164 i 410 j 150 s 122


a 187 b 590 c 410 f ≥ 164 i 410 j 150 s 122

Required wall quality

Brickwork

d ≥ 200 mm

Concrete

d ≥ 200 mm

Aerated concrete

d ≥ 200 mm

Assembly walls

d ≥ 160 mm

planked steel construction

acc. to DIN 4102-4

approval range (max 13.6sqm)

LB

4500 mm

LH

4500 mm

technical feasibility

LB

4500 mm

LH

5100 mm
Constructive structure - System drawing - Vertical

a 245 b 660 c 550/625 e ≥ 0 s 122


a 245 b 660 c 550/625 e ≥ 0 s 122

Required wall quality

Brickwork

d ≥ 200 mm

Concrete

d ≥ 200 mm

Aerated concrete

d ≥ 200 mm

Assembly walls

d ≥ 160 mm

planked steel construction

acc. to DIN 4102-4

approval range (max 12,1sqm)

LB

4500 mm

LH

4500 mm

technical feasibility (max 20,25sqm)

LB

4500 mm

LH

5100 mm
